    4 to 20mA output universal input DIN Rail temperature transmitter TMT131A RTD TC PT100 2 wire 3wireGalvanic isolation

    Ask Lasest Price
    Brand Name : SENSE
    Model Number : TMT131A
    Payment Terms : T/T
    Supply Ability : 10000PCS / Month
    Delivery Time : 5-8 workdays
    • Product Details
    • Company Profile

    4 to 20mA output universal input DIN Rail temperature transmitter TMT131A RTD TC PT100 2 wire 3wireGalvanic isolation

    4 to 20mA output universal input DIN Rail temperature transmitter TMT131A RTD TC PT100 2 wire 3wireGalvanic isolation

    • DIN rail temperature transmitter TMT131A for resistance
    • thermometers(RTD),thermocouples(TC), resistance and voltage
    • transmitters,settable via HART-protocol
    • High performance, high reliability
    • Variety of sensor inputs
    • Hart Digital communication
    • ​Self-diagnostics function

    Performance
    • Temperature transmitter for converting various input signals into a scalable 4 to 20 mA analogue output signal

    Input
    • Resistance thermometer (RTD)
    • Thermocouple (TC)
    • Resistance transmitter (Ω)
    • Voltage transmitter (mV)
    Performance
    • ​Universal settings for various input signals
    • 2 wire technology, 4 to 20mA analogue output
    • High accuracy in total ambient temperature range
    • Galvanic isolation 2000V AC
    • An internal temperature sensor for active temperature
    • compensation(For T/C)
    • Wide voltage supply range
    • Customer speciϐic measurement range settings
    • Expanded resistance input (max. 2KΩ)
    • Expanded voltage input (max. 2KmV)
    InputTypeMeasurement RangesMin.meas.ranges
    Resistance thermonmeter(RTD)PT100-200℃ to 850℃(-328℉ to 1562℉)10K
    Resistance thermonmeter(RTD)PT500

    ►-200℃ to 250℃(-328℉ to 482℉)

    10K
    Resistance thermonmeter(RTD)PT1000-200℃ to 250℃(-328℉ to 482℉)10K
    Resistance thermonmeter(RTD)Cu50►-50℃ to 150℃(-58℉ to 302℉)10K
    Resistance thermonmeter(RTD)Cu100►-50℃ to 150℃(-58℉ to 302℉)10K
    Resistance thermonmeter(RTD)Ni100►-60℃ to 180℃(-76℉ to 356℉)10K
    Resistance thermonmeter(RTD)Ni500►-60℃ to 180℃(-76℉ to 356℉)10K
    Resistance thermonmeter(RTD)Ni1000►-60℃ to 150℃(-76℉ to 302℉)10K
    Resistance thermonmeter(RTD)Resistance(Ω)0Ω to 400Ω10Ω
    Resistance thermonmeter(RTD)Resistance(Ω)0Ω to 2000Ω20Ω
    Connection type: 2-wire, 3wire, 4wire connection
    Thermocouples
    (TC)
    B(PtR30-PtRh6)0℃ to 180℃(-32℉ to 3308℉)500K
    Thermocouples
    (TC)
    E(NiCr-CuNi)-270℃ to 1000℃(-454℉ to 1832℉)50K
    Thermocouples
    (TC)
    J(Fe-CuNi)-210℃ to 1200℃(-346℉ to 2192℉)50K
    Thermocouples
    (TC)
    K(NiCr-Ni)-270℃ to 1372℃(-454℉ to 2501℉)50K
    Thermocouples
    (TC)
    N(NiCrSi-NiSi)-270℃ to 1300℃(-346℉ to 2372℉)50K
    Thermocouples
    (TC)
    R(PtRh13-Pt)-50℃ to 1768℃(-58℉ to 3214.4℉)500K
    Thermocouples
    (TC)
    S(PtRh10-Pt)-50℃ to 1768℃(-58℉ to 3214.4℉)500K
    Thermocouples
    (TC)
    T(Cu-CuNi)-270℃ to 400℃(-454℉ to 752℉)50K
    Voltage transmitters(mV)Millivolt transmitter(mV)-75mV to 75V5mV
    Voltage transmitters(mV)Millivolt transmitter(mV)-700mV to 200V20mV
    ► ON Request

    Electrical connections


    Dimensions

    Installation diagram


    Ordering code

    Certification
    A
    B
    Version for non hazardous areas
    NEPSI Ex ia CT4
    Configuration transmitter connection
    A
    1
    2
    3
    4
    Standard factory configuration 3-wire
    Configuration
    Configuration
    Configuration
    Configuration
    connection TC
    connection RTD(2-wire)
    connection RTD(3-wire)
    connection RTD(4-wire)
    Configuration temperature sensor
    A
    1
    2
    3
    4
    5
    6
    7
    8
    B
    E
    J
    K
    N
    R
    S
    T
    Standard factory configuration Pt100
    Pt100-200℃ to 850℃(-328°Fto 1562°F)
    Pt500-200℃ to 250℃(-328°F to 482"F)
    Pt500-200℃ to 250℃(-328F to 482°F)
    Pt1000-200℃ to 250℃(-328°F to 482°F)
    Cu50 -50℃ to 150℃(-58°F to 302°F)
    Cu100-50℃ to 150℃(-58°F to 302°F)
    Ni100-60℃ to 180℃ (-76°Fto 356°F)
    Ni500-60℃ to 180℃(-76°Fto 356°F)
    Type B 0℃ to 1820℃(-32°F to 3308°F
    Type E -270℃ to 1000℃(-454F to 1832°F)
    Type J-210℃ to 1200℃(-346°Fto 2192°F)
    Type K-270℃ to 1372℃(-454°F to 2501F)
    Type N -270℃ to 1300℃(-454°F to 2372°F)
    Type R -50℃ to 1768℃(-58°F to 3214.4°F)
    Type S-50℃ to 1768℃(-58°Fto 3214.4°F)
    Type T -270℃ to 400℃(-454°F to 752°F)
    Configuration
    A
    B
    C
    D
    Standard factory configuration(Pt100/3-wire/0 to 100℃)
    Customised measurement range
    Customised expanded configuration for TC
    Customised expanded configuration for RTD
    TMT131AOrder code(complete) For example:TMT131A-AAAA
